18 F-Choline-PET/CT for non-FDG-avid salivary gland cancer: a preliminary report

EJNMMI Research volume 14, Article number: 68 (2024) Cite this article

Introduction

Malignant salivary gland tumors are rare, accounting for 1–3% of all head and neck cancers [1, 2]. Primary tumors of the salivary gland show a wide variety of morphological entities, with additional subtypes continuously being described [3, 4]. The two most significant prognostic factors are histologic tumor grade and the clinical stage at presentation [5].

Initial staging of malignant salivary gland disease usually involves cross-sectional imaging with contrast-enhanced computed tomography (CT) or magnetic resonance imaging (MRI). Fluoro-desoxy-glucose (FDG) position emission tomography combined with CT or MRI (hybrid FDG-PET) has been increasingly used in salivary gland tumors [6]. However, a subset of primary salivary gland tumors, such as adenoid cystic carcinoma and/or, low-grade salivary gland carcinoma, typically does not exhibit high FDG uptake. Further, FDG uptake alone can be misleading as it can be high in benign entities such as Warthin tumor or benign oncocytic tumors [6].

We therefore felt appropriate to evaluate the potential role of the non-FDG tracer 18F-choline in imaging of salivary gland tumors. Our goal was to evaluate the added value of a potentially more specific radiotracer.

Methods

After obtaining ethics review board approval and informed consent of the patients, we prospectively included patients with clinical and cytological strong suspicion of malignant salivary gland tumors. All patients underwent hybrid FDG-PET followed by hybrid choline-PET. Surgery was offered as a primary treatment modality in resectable cases. Surgical pathology was reviewed by a dedicated head and neck pathologist (NJR) and classified pursuant to the 2017 update of the WHO classification [3].

Results

The cohort included five prospectively enrolled patients (Table 1). Four cases had cytologically proven malignant (Milan category VI) salivary gland neoplasms. In addition, one case of cytological “salivary gland neoplasm of uncertain malignant potential” (SUMP; Milan category IVb) was included [7].

Table 1 Overview of the patients included in the pilot study
Full size table

On final pathology, one case was a parotid gland high-grade mucoepidermoid carcinoma, one case of classical (low-grade) acinic cell carcinoma, one case of high-grade adenocarcinoma NOS, which would be classified as (high-grade) mucinous adenocarcinoma according to the forthcoming WHO 2023 classification. The other malignant case was an adenoid cystic carcinoma of the submandibular gland (Table 1).

All malignant cases showed low uptake of the primary tumor on FDG-PET (average SUVmax 2.9), while the uptake was higher on choline-PET (mean SUVmax 8.5) (see Figs. 1 and 2). One case had positive nodal disease and the nodal uptake was higher in hybrid choline-PET than in hybrid FDG-PET (7.4 vs. 2.9, respectively).

Fig. 1
figure 1

(A) axial hybrid FDG-PET/CT images of patient 3 with high grade adenocarcinoma of the left parotid showing low uptake of the tumor (SUVmax 2.4). (B) axial hybrid choline-PET/CT images of patient 3 with high grade adenocarcinoma of the left parotid, showing moderate uptake of tumor (SUVmax 7.2). (C) maximum intensity projection (MIP) of patient 3 on FDG-PET showing almost no uptake in the parotid gland (and typical uptake in the brain, heart, and lower urinary tract). (D) maximum intensity projection (MIP) of patient 3 on choline-PET showing uptake in salivary glands (and in the tumor) and choline uptake in the liver, pancreas, kidney, and spleen

Full size image
Fig. 2
figure 2

1A-1D: Axial hybrid FDG-PET/CT (1A), axial hybrid choline-PET/CT (1B), maximum intensity projection (1C) on FDG-PET, and maximum intensity projection of choline-PET (1D) of patient 1 with high-grade mucoepidermoid carcinoma of left parotid

2A-2D: Axial hybrid FDG-PET/CT (2A), axial hybrid choline-PET/CT (2B), maximum intensity projection (2C) on FDG-PET, and maximum intensity projection of choline-PET (2D) of patient 2 with low-grade acinic cell carcinoma of right parotid

4A-4D: Axial hybrid FDG-PET/CT (4A), axial hybrid choline-PET/CT (4B), maximum intensity projection (4C) on FDG-PET, and maximum intensity projection of choline-PET (4C4D) of patient 4 with adenoid cystic carcinoma of left submandibular gland

5A-5D: Axial hybrid FDG-PET/CT (5A), axial hybrid choline-PET/CT (5B), maximum intensity projection (5C) on FDG-PET, and maximum intensity projection of choline-PET (5D) of patient 5 with pleomorphic adenoma of left parotid gland

Full size image

Interestingly, the uptake of the primary tumor was stronger in choline PET than FDG-PET. In particular, the case of adenoid cystic carcinoma also showed relative high choline uptake, even though adenoid cystic carcinoma are known to be frequently non-FDG-avid [6]. However, also the background uptake by physiologic salivary gland tissue was considerably higher with choline PET compared to FDG-PET.

The fifth case was a patient with a salivary gland neoplasm of uncertain malignant potential (SUMP) who underwent FDG-PET and choline PET, in which final pathology revealed a cellular pleomorphic adenoma. The choline SUVmax of the tumor was 5.5, which, albeit lower than in malignant tumors, remains comparable to these (mean SUVmax 8.5).

Discussion

Our limited data represents, to the best our knowledge, the first description of the potential use of hybrid choline-PET in salivary gland neoplasms. We chose choline as it is incorporated in cell membrane phospholipids through phosphorylation [8]. Malignant transformation of cells is associated with induction of choline kinase activity, whereas phosphoryl choline is thought to be present at low or undetectable levels in normal tissues [8]. Although our data shows that choline was somewhat superior to FDG for salivary gland cancer, especially low-grade tumors and adenoid cystic carcinoma, mainly owing to the comparably high physiologic background uptake that impacts the assessment of the primary tumor, the imaging results were not strongly convincing for us to continue our endeavour for these patients, or encourage other groups to test choline-PET for this purpose. Future works may, however, address the issue of nodal staging or test the potential use of choline-PET for detection of distant metastasis of salivary gland cancer. It is important to report our limited experience, as more appropriate radiotracers are needed for salivary gland neoplasms, particularly for adenoid cystic carcinoma, in which FDG-PET typically performs poorly [6].

Other non-FDG radiotracer have been evaluated for salivary gland tumors. Prostate-specific membrane antigen (PSMA), which has broad clinical application in prostate cancer, is known to accumulate in normal salivary gland tissue [9]. Some authors reported stronger uptake in salivary gland tumors than “normal” salivary gland tissue [10]. In addition, the use of PSMA PET and PSMA radioligand therapy (177Lu-PSMA-617) has been reported for detection and treatment of metastatic adenoid cystic carcinoma; however the radioligand therapy effects were limited [11, 12]. In addition, the use of PSMA-targeting radiopharmaceuticals could be further restricted due to their toxicity to the salivary glands. Another novel group of radiotracers that showed encouraging results in salivary gland carcinoma are the fibroblast activation protein inhibitors (FAPI) [13].

Conclusion

Novel, more specific radiopharmaceuticals are needed in patients with some types of primary salivary gland carcinoma. Our report shows limited benefit of the use of choline over fluoro-desoxy-glucose for hybrid PET imaging in salivary gland malignancies.

Data availability

The datasets generated for this study can be obtained upon reasonable request by email to the corresponding author.

Abbreviations

CT:

Computed tomography

FAPI:

Fibroblast activation protein inhibitors

FDG:

Fluoro-desoxy-glucose

MRI:

Magnetic resonance imaging

PET:

Position emission tomography

PSMA:

Prostate-specific membrane antigen

SUMP:

Salivary neoplasm of unknown malignant potential

WHO:

World health organization

References

  1. Hadiprodjo D, Ryan T, Truong MT, Mercier G, Subramaniam RM. Parotid gland tumors: preliminary data for the value of FDG PET/CT diagnostic parameters. AJR Am J Roentgenol. 2012;198:W185–90. https://doi.org/10.2214/AJR.11.7172.

    Article  PubMed  Google Scholar

  2. Everson JWAP, Gnepp DR, El-Naggar AK. Tumors of the salivary glands. In: Barnes LEJ, Reichart P, Sidransky D, editors. World Health Organization Classification of Tumors Pathology and Genetics of Head and Neck tumors. Lyon: IARC; 2005. pp. 212–5.

    Google Scholar

  3. Seethala RR, Stenman G. Update from the 4th Edition of the World Health Organization Classification of Head and Neck tumours: tumors of the salivary gland. Head Neck Pathol. 2017;11:55–67. https://doi.org/10.1007/s12105-017-0795-0.

    Article  PubMed  PubMed Central  Google Scholar

  4. Morand GB, Eskander A, Fu R, de Almeida J, Goldstein D, Noroozi H, et al. The protective role of postoperative radiation therapy in low and intermediate grade major salivary gland malignancies: a study of the Canadian Head and Neck Collaborative Research Initiative. Cancer. 2023;129:3263–74. https://doi.org/10.1002/cncr.34932.

    Article  CAS  PubMed  Google Scholar

  5. Hocwald E, Korkmaz H, Yoo GH, Adsay V, Shibuya TY, Abrams J, et al. Prognostic factors in major salivary gland cancer. Laryngoscope. 2001;111:1434–9.

    Article  CAS  PubMed  Google Scholar

  6. Karimian S, Hüllner MW, Rupp NJ, Freiberger SN, Broglie MA, Morand GB. Potential role of hybrid positron emission tomography in pre-operative assessment of primary salivary gland carcinomas. J Laryngology Otology. 2023;137:551–5.

    Article  CAS  Google Scholar

  7. Morand GB, Alsayegh R, Mlynarek AM, Plourde M, Mach T, Mascarella MA, et al. Application of the Milan system for reporting salivary gland cytopathology using cell blocks. Virchows Arch. 2022;481:575–83.

    Article  CAS  PubMed  Google Scholar

  8. Roivainen A, Forsback S, Grönroos T, Lehikoinen P, Kähkönen M, Sutinen E, et al. Blood metabolism of [methyl-11 C] choline; implications for in vivo imaging with positron emission tomography. Eur J Nucl Med Mol Imaging. 2000;27:25–32.

    Article  CAS  Google Scholar

  9. Rupp NJ, Umbricht CA, Pizzuto DA, Lenggenhager D, Töpfer A, Müller J, et al. First clinicopathologic evidence of a non–PSMA-related uptake mechanism for 68Ga-PSMA-11 in salivary glands. J Nucl Med. 2019;60:1270–6.

    Article  CAS  PubMed  Google Scholar

  10. Isgoren S, Hekimsoy T, Koroglu E, Demir H. PET/CT with 68Ga-PSMA and 18F-FDG in metastatic adenoid cystic carcinoma: report of 2 cases. Clin Nucl Med. 2022;47:e423–4. https://doi.org/10.1097/rlu.0000000000004106.

    Article  PubMed  Google Scholar

  11. Civan C, Kasper S, Berliner C, Fragoso-Costa P, Grünwald V, Pogorzelski M, et al. PSMA-directed imaging and therapy of salivary gland tumors: a single-center retrospective study. J Nucl Med. 2023;64:372–8.

    Article  CAS  PubMed  PubMed Central  Google Scholar

  12. Klein Nulent TJ, van Es RJ, Willems SM, Braat AJ, Devriese LA, de Bree R, et al. First experiences with 177 Lu-PSMA-617 therapy for recurrent or metastatic salivary gland cancer. EJNMMI Res. 2021;11:1–6.

    Article  Google Scholar

  13. Röhrich M, Syed M, Liew DP, Giesel FL, Liermann J, Choyke PL, et al. (68)Ga-FAPI-PET/CT improves diagnostic staging and radiotherapy planning of adenoid cystic carcinomas - imaging analysis and histological validation. Radiother Oncol. 2021;160:192–201. https://doi.org/10.1016/j.radonc.2021.04.016.

    Article  CAS  PubMed  PubMed Central  Google Scholar
